Specifications

The refrigerator is electric from the onboard power supply of the car 12 v from the external net work
Standby - 220 v

Mounting type: rooftop
Cooling capacity: 0.8 kW
Airflow: 1150 m%/h
Control: standard vehicle control unit
Scroll compressor CC20
Refrigerant: R134A (900 $ 50 g) |
Condenser unit net weight: 18 kg
Evaporator unit net weight: 9.3 kg
Condensing unit dimensions: 1200 x 570 x 180
min
Evaporator unit dimensions: 700 x 520 x 170 mm
Rated on-board Power Consumption (12V DC): 75
Rated Power Consumption (220V AC): 1000 W

The refrigerated truck is designed for an insulated van with a volume of up to 4 m'.
At an ambient temperature of +30°C, the van maintains 10°C.
At an ambient temperature of +45°C, the van maintains 2'C.

Specifications

Refrigerated unit (Freezer) with direct drive, 12V vehicle

Type of Installation: Roof-mounted
Cooling Capacity: 2.8 kW
Airflow: 2300 m³/h
Control: Standard transport control
Compressor: 5H14 – 7H15
Refrigerant: R404A (1200 ± 50 g)
Condenser Unit Weight: 16 kg (net)
Evaporator Unit Weight: 21 kg (net)
Condenser Unit Dimensions: 990 × 570 × 160 mm
Evaporator Unit Dimensions: 760 × 540 × 210 mm
Rated Current Consumption (on-board 12V system): 45 A

Vehicle Refrigeration Unit
Designed for an insulated van with a volume of up to 12 m³.
At an ambient temperature of +30 °C, the van temperature is maintained at -20 °C.
At an ambient temperature of +45 °C, the van temperature is maintained at -17 °C.

Specifications

Vehicle Chiller with Direct Drive, 12V

Type of Installation: Roof-mounted
Cooling Capacity: 2.4 kW
Airflow: 2300 m³/h
Control: Standard transport control
Compressor: 7H15
Refrigerant: R134A (1200 ± 50 g)
Condenser Unit Weight: 16 kg (net)
Evaporator Unit Weight: 21 kg (net)
Condenser Unit Dimensions: 990 × 570 × 160 mm
Evaporator Unit Dimensions: 760 × 540 × 210 mm
Rated Current Consumption (on-board 12V system): 35 A

Vehicle Refrigeration Unit
Designed for an insulated van with a volume of up to 12 m³.
At an ambient temperature of +30 °C, the van temperature is maintained at -5 °C.
At an ambient temperature of +45 °C, the van temperature is maintained at 0 °C.

Specifications

Vehicle Refrigeration Unit
with Direct Drive, 12–24 V from the vehicle power supply
Standby – 220 V

Type of Installation: Roof-mounted
Cooling Capacity: 5.0 kW
Cooling Capacity: 3.5 kW
Airflow: 3400 m³/h
Control: Standard transport control
Compressor: 7H15
Compressor: CC36
Refrigerant: R404A (1500 ± 50 g)
Condenser Unit Weight: 60 kg (net)
Evaporator Unit Weight: 30 kg (net)
Condenser Unit Dimensions: 950 × 950 × 238 mm
Evaporator Unit Dimensions: 1340 × 540 × 210 mm
Rated Current Consumption (on-board 12V system): 52 A
Rated Power Consumption (external 220V supply): 2500 W

Vehicle Refrigeration Unit
Designed for an insulated van with a volume of up to 20 m³.
At an ambient temperature of +30 °C, the van temperature is maintained at -20 °C.
At an ambient temperature of +45 °C, the van temperature is maintained at -18 °C.

Specifications

Vehicle Refrigeration Unit
with Direct Drive, 12–24 V from the vehicle power supply
Standby – 220 V

Type of Installation: Roof-mounted
Cooling Capacity: 6.0 kW
Cooling Capacity: 3.5 kW
Airflow: 3400 m³/h
Control: Standard transport control
Compressor: 7H15-TM-21
Compressor: CC36
Refrigerant: R404A (1500 ± 50 g)
Condenser Unit Weight: 18 kg (net)
Evaporator Unit Weight: 30 kg (net)
Condenser Unit Dimensions: 960 × 490 × 170 mm
Evaporator Unit Dimensions: 1340 × 540 × 210 mm
Rated Current Consumption (on-board 12V system): 52 A
Rated Power Consumption (external 220V supply): 2500 W

Vehicle Refrigeration Unit
Designed for an insulated van with a volume of up to 20 m³.
At an ambient temperature of +30 °C, the van temperature is maintained at -20 °C.
At an ambient temperature of +45 °C, the van temperature is maintained at -18 °C.
